MAN TG3 Additional Cooling Control Wiring Diagram – TGX/TGS Euro 6d (Q4 2020)

This official wiring schematic details the Additional Cooling Control system for MAN TG3 series trucks (TGX and TGS) equipped with Euro 6d engines. It includes a comprehensive view of the fan drive control (Regelventil Lüfterantrieb), EIO2 module, and CAN I-CAN data bus structure.

Prepared by MAN Truck & Bus SE at Werk München, this Q4 2020 release is ideal for:

• Troubleshooting fan control issues
• Diagnosing CAN communication faults
• Workshop repairs and electronic retrofitting
• Cross-checking wiring with MANTIS EPC

All diagrams are full-scale A2 and formatted for professional use in OEM and aftermarket environments.

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
