MAN TG3 CAN Nodes & LIN/PTX Wiring Diagrams – TGX/TGS Euro 6d (Q4 2020)

This 8-part official wiring set illustrates the CAN bus architecture and LIN/PTX integration for MAN TG3 TGX/TGS Euro 6d trucks, sourced directly from MAN Truck & Bus SE (Werk München), Q4 2020 edition.

This advanced schematics package details each communication layer in the truck’s electrical system, from powertrain and cabin modules to diagnostics and telematics.

🧠 Key components and systems covered:

• CAN networks: I-CAN, M-CAN, D-CAN, O3-CAN, C-CAN, T-CAN, G-CAN
• Control modules: CVM, EIO1/2/3, PTY, EMOS, TRAXON, RIO, EBS, ESA, EPB, ECAS, Airbag, Infotainment
• Telematics & diagnostic nodes: DSRC, DTCO, VCM, TBM, and OBD connectors
• LIN bus layout: LIN 1–5 architecture for ECAS, lighting, fan clutch, flame-start relay, cab switches
• PTY-specific routing: Engine brake solenoids, oil sensors, fan module, and CAN_3 routing

🧩 All connectors (X64xx series), resistors (R122, RP005), and diagnostic points (XP200) are clearly labeled for high-precision reference.

Perfect for:

• Advanced diagnostics and retrofit planning
• Vehicle telematics and body-builder interface work
• CAN-based fault tracing using MAN CATS or engineering tools
• Workshop training and system integration studies

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
