MAN TG3 Driver Assistance Wiring Diagrams – TGX/TGS Euro 6d (Q4 2020)

EM wiring set provides comprehensive schematics for the Driver Assistance Systems in MAN TG3 TGX/TGS Euro 6d trucks, released by MAN Truck & Bus SE (Werk München), Q4 2020. It includes all signal paths, CAN and LIN integration, sensor wiring, and control modules related to key active safety features.

🧠 Covered Systems & Components:

✅ Advanced Emergency Braking (AEBS/EBA)

• Taster AEBS (S675.1) to CVM
• ACC sensor (B574.1) and fuse control (F413.1)

✅ Lane Guard System (LGS)

• Lane Assist Button (S685.1)
• Lane departure feedback LEDs & deactivation control
• CVM + CAN I/O mapping via AP025 and A100.1

✅ Side Range Radar (SRR) – Turn Assist

• Radar units AV1015–AV1018 (left/right, front/rear)
• Warning indicators (AV1019.1 / AV1020.1)
• Control button for lane change assist (S1431.1)
• CAN and LIN integration via A1363.2 and AP030

✅ Telematics and RIO Integration

• A1266.1 (Telematik Bordmodul 2)
• CAN lines: O-CAN, I-CAN, D-CAN
• PFB ATO interface (AP021) and “Brotbox” left/right signal routing

🛠️ All connector references (e.g. X6301, X6425, X6433, XBROTL, XBROTR) and harness part numbers are included for high-precision diagnostics and retrofitting.

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
