Porsche Panamera A/C System Wiring Manual (2015–2016)

This specialized OEM wiring manual focuses exclusively on the Air Conditioning (A/C) system of the Porsche Panamera models from 2015 to 2016. Perfect for HVAC diagnostics, sensor tracing, and component replacement, it features clear schematics directly sourced from Porsche’s technical documentation.

❄️ Included in this manual:

• Complete A/C control circuit diagrams

• Compressor, pressure sensor, and fan wiring

• Air distribution flap motor control (front & rear zones)

• CAN communication with HVAC control unit

• Ground, fuse, and relay layout for HVAC system

• Diagnostic input/output signal paths

🔧 Use cases:

• Fault-tracing A/C system failures

• Intermittent HVAC performance troubleshooting

• Retrofitting or replacing the HVAC control module

• Understanding HVAC sensor logic in Panamera models

🧩 Fits:

• Porsche Panamera Base, S, 4S, Turbo, and E-Hybrid

• Sedan and Executive models (2015–2016)

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
