VW Golf 7 Auxiliary Heater Workshop Manual PDF (Edition 11.2016)

14,99

12 Items sold in last week
20 People watching this product now!

Payment Methods:

Description

Master the VW Golf’s auxiliary (supplementary) heating system with this official 2016 workshop manual. Covering Golf Mk7, Variant, GTE, and compatible 2013–2017 models, it delivers:

  • Technical Data & Capacities for heater operation, coolant flow, fuel metering pump, and control-unit parameters
  • Safety & Identification: fire, exhaust-fume, high-voltage and fuel-system precautions, type-plate decoding
  • Repair Notes & Cleanliness Rules: gasket, seal and fastener guidance, wiring-harness routing
  • Supplementary Heating Procedures: heater removal/installation, burner unit overhaul, blower, silencer, pump service
  • Coolant & Fuel Circuits: hose-bleeding, pump tests, metering-pump bleeding, sensor replacements
  • Control & Diagnostics: actuator settings, timer functions, remote-control receiver service, fault-code reading

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.

Table of Contents

Technical data

Safety information

  • Safety precautions when working on vehicles with auxiliary heater
  • Safety measures when working on vehicles with a start/stop system
  • Safety precautions during work on fuel system
  • Safety precautions when working on cooling system
  • Safety precautions when using test and measuring equipment during a road test
  • Safety precautions when working on high-voltage system
  • Safety precautions when working in the vicinity of high-voltage components

General information

  • Starting conditions for auxiliary heater, auxiliary heater mode
  • Starting conditions for auxiliary heater, supplementary heater mode
  • Notes for vehicles with start-stop system
  • Rules for cleanliness when working on auxiliary heater and fuel system
  • Type plates

Repair notes

  • General repair instructions

Overview of fitting locations – auxiliary heater components

  • Golf and Golf GTE overview
  • Golf Estate overview

Auxiliary heater

  • Assembly overview – attachments
  • Assembly overview – internal components
  • Removing and installing auxiliary heater
  • Dismantling and assembling auxiliary heater
  • Removing and installing air intake silencer
  • Removing and installing circulation pump
  • Removing and installing exhaust system
  • Removing and installing auxiliary heater bracket
  • Removing and installing covers for auxiliary heater control unit
  • Removing and installing glow plug with flame monitor
  • Removing and installing temperature and overheating sensors
  • Connector pin assignments

Coolant circuit with auxiliary heater

  • Connection diagram – coolant hoses
  • Bleeding coolant circuit
  • Removing and installing coolant pipes for auxiliary heater

Fuel supply system

  • Overview of fitting locations – fuel supply system
  • Checking fuel delivery rate
  • Removing and installing metering pump
  • Checking metering pump with end-sealing valve
  • Bleeding fuel line to metering pump

Regulation of auxiliary heater

  • Function description
  • Supplementary heating mode
  • Auxiliary heater mode
  • Switching off auxiliary heater

Other controlling and regulating components

  • Removing and installing ambient temperature sensor
  • Removing and installing remote-control receiver
  • Functional description of remote control
