MAN TG3 Airbag Control Wiring Diagram – TGX/TGS Euro 6d (Q4 2020)

This high-detail wiring diagram outlines the Airbag Control System for MAN TG3 TGX/TGS Euro 6d trucks, sourced directly from MAN Truck & Bus SE (Werk München), with release reference Q4 2020.

The schematic covers all airbag-related elements, including:

• Steuergerät Airbag (A1165)
• Gurtstraffer (Seatbelt Pretensioners)
• Wickelfeder (Clockspring)
• CAN integration points (I-CAN Bus)
• Grounding paths (EMV Gehäuse Masse)

Ideal for auto-electricians, retrofitters, or diagnostic technicians working with safety systems in TG3-generation trucks.

Includes full connector labeling (X6428, X6430, X6479, X6442, etc.) and fuse assignments.

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
