MAN TG3 Ground Net Wiring Diagram – TGX/TGS Euro 6d (Q4 2020)

9,99

13 Items sold in last week
16 People watching this product now!

Payment Methods:

Description

This OEM schematic from MAN Truck & Bus SE – Werk München provides the full Ground Net (Massepunkte) electrical layout for MAN TG3 TGX/TGS Euro 6d vehicles. Dated Q4 2020, this diagram is essential for understanding all primary and auxiliary grounding points across the chassis, cab, and system interfaces.

🔩 System Features:

  • Ground points across multiple system groups including:

    • SYS_airbagControl

    • SYS_canNodes

    • SYS_cluster

    • SYS_doorControl

    • SYS_exteriorLights

    • SYS_frameLevelControl

    • SYS_driverAssistance

    • SYS_auxiliaryPowerSupply

    • SYS_warningBeacon

    • SYS_airCondition, tailLift, interiorLights, seat, sunBlind, etc.

  • Key connectors:

    • X6395.1 – Ground FHS left

    • X6396.1 – Ground FHS right

    • X7429 – Body builder ground

  • Integration with CVM, RIO, ECAS, EBS (Knorr/Wabco), Retarder, and TPMS modules

  • Large-scale connector and module mapping across systems via 16 mm² bonding wires

  • Diagrams reference chassis and cab ground continuity for all signal, logic, and actuator lines

🔧 Ideal for:

  • Ground fault tracing

  • CAN/diagnostic interference resolution

  • Retrofitting equipment to compliant chassis points

  • Body builder grounding & safety system adaptation


Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
