MAN TG3 HydroDrive Wiring Diagrams – TGX/TGS Euro 6d (Q4 2020)

9,99

14 Items sold in last week
7 People watching this product now!

Payment Methods:

Description

OEM wiring set outlines the complete HydroDrive (Hydrostatische Vorderachse) system for MAN TG3 TGX/TGS Euro 6d trucks, as published by MAN Truck & Bus SE (Werk München), Q4 2020. The HydroDrive system is a hydraulically driven front axle solution that activates under traction-demanding conditions, typically used in off-road or municipal transport applications.

🛠️ System Components & Functions:

  • Solenoid Valves (Y305):

    • Y384.1 – Clutch valve (main pump)

    • Y385.1 – Main valve 1

    • Y386.1 – Main valve 2

    • Y387.1 – Feed pump valve

  • Sensors:

    • B551.1 – Oil temperature (hydrostatic front axle)

    • B620.1 – Oil pressure (HydroDrive)

    • BV117.1 – RPM sensor (HVA pump)

  • Actuators & Cooling:

    • K934.1 – Hydro fan relay

    • M196.1 – Oil cooler fan motor

  • Control Modules:

    • A1358.1 – RIO

    • A1363.2 – CVM (AP025)

    • A100.1 – Zentralelektrik

  • CAN/LIN Integration:

    • CAN 5 High/Low from CVM and RIO

    • LIN control via differential lock switch

  • Ground/Power Paths:

    • SYS_groundNet

    • SYS_electricalPowerSupply

    • Relay and fuse routing for K280, F720.1

🧩 Additional Connectors:

  • X6302, X6490, X6478, X6816 (frame-to-cab connectors for HydroDrive)

  • Preconfigured with harness sets (e.g., 81.25475-0283, -0453, -6033)

Ideal for:

  • Diagnosing HydroDrive activation or pressure failures

  • Planning or retrofitting 4×4 hydraulic traction

  • Tracing sensor feedback through CAN and LIN to CVM/ECU

  • Heavy terrain fleet and refuse vehicle maintenance teams


Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
