Navistar Diamond Logic Builder (DLB) Chassis Diagnostic & Programming Software

The Navistar® Diamond Logic™ Builder software provides the ability to program, diagnose and simulate features in the Electrical System Controller or Body Controller (ESC/BC) module on the Industry’s First High-Performance Trucks®. The Diamond Logic™ Builder program allows users to configure switches, the gauge cluster, and the parameters that are programmed in the ESC/BC.

version: 15814

release: 6.2022

Supported languages: English

Diamond Logic Builder features:

• Read Fault and clear diagnostic fault codes
• View vehicle parameters and features
• Bi-directional control of electrical components
• View switch location and cluster configuration
• Automatic module detection
• Graph parameters
• Record snapshots

Diamond Logic Builder Coverage:

• international 4200/4300/4400 Series
• International 7000 Series
• International 8000 Series
• International CF Series (Cluster faults, Test all gauges except fuel, Odometer set)
• International ProStar/LoneStar/WorkStar/TranStar/DuraStar/CityStar

Minimum system requirements:

• AMD or Intel Celeron/Pentium CPU 1.5 GHz or higher,
• 2 GB RAM or higher
• 2 GB free space,
• USB 1.1 port (USB 2.0 recommended)
• Microsoft Windows 7 SP1 or higher

Installation: Upon successful payment, you will promptly receive an email containing the download link. Should you encounter any delays in receiving this email, we recommend checking your spam folder or reaching out to us via the live chat using the icon located at the bottom right corner of the screen. It's worth noting that the majority of our packages are stored in a MEGA premium account, ensuring a seamless download experience. Should you encounter any challenges during the download process, our team is readily available to assist you. If you opt for the "Remote Installation" option during checkout, rest assured that we will manage all aspects of the installation and configuration through a UltraViewer or AnyDesk session, ensuring a smooth setup process.
