Porsche Panamera 2015-2016 Passenger Seat Memory System Wiring Manual

This detailed Passenger Memory Seat Circuit Manual for the Porsche Panamera 2015–2016 models covers both standard and sport comfort seat configurations, offering complete electrical schematics and connector references. It includes:

• Adjustment Motors (Standard & Sport Comfort):

  • Fore & Aft

  • Backrest Recline

  • Seat Height

  • Seat Angle

  • Seat Depth (Sport Comfort)

• Advanced Comfort Functions (Sport version):

  • Lumbar Support (Top/Bottom, Forward/Backward, High/Low)

  • Ventilation Valves (1–4) and Bleeding Valves (1–4)

  • Positive Valve & Valve Block Integration

  • Integrated Hall Sensor Feedback for positioning

• Control Units & Switching Modules:

  • Passenger Door Control Unit

  • Seat Adjustment Output Control Unit

  • Seat Memory Button Module

• CAN Bus Communication:

  • CANHIGH and CANLOW integrated for memory coordination with the ECU

• Grounding & Power Distribution:

  • Multiple shared grounds, dedicated fuses, and SOF relays

  • Fuse Box Reference: Right Kick Panel

Designed for diagnostics, retrofits, and technical maintenance, this manual enables accurate tracing and testing of all memory seat-related circuits in Porsche Panamera front passenger systems.

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
