Vehicle Coverage
- 2015 Ford E-350 Super Duty Base – source manual header identifies 6.8L; additional 5.4L CNG, Flex Fuel and LPG plus 6.8L/CNG/LPG engine and transmission sections are included
- 2016 Ford E-350 Super Duty Base – source manual header identifies 5.4L; includes 5.4L CNG, Flex Fuel and LPG plus 6.8L/CNG/LPG powertrain sections
- 2018 Ford E-350 Super Duty Base – source manual header identifies 6.8L; includes 6.2L Flex Fuel plus 6.8L, 6.8L CNG and 6.8L LPG engine-performance sections
- 2019 Ford E-350 Super Duty Base – source manual header identifies 6.2L; includes 6.2L Flex Fuel plus 6.8L, 6.8L CNG and 6.8L LPG engine-performance sections
- 2022 Ford E-350 Super Duty Base – 7.3L engine electrical coverage
- Body configurations: cutaway and stripped-chassis circuits where identified by the manuals
- Package: 5 PDF wiring manuals / 420 pages
- Language: English
Technical Highlights
- Factory-style electrical schematics for selected Ford E-350 Super Duty applications
- Engine-performance wiring for 5.4L, 6.2L, 6.8L and 7.3L applications, including CNG, LPG and Flex Fuel variants where included
- TorqShift transmission circuits on applicable 2015 and 2016 powertrain variants
- Body Control Module (BCM), computer data lines and module communication networks
- Power distribution, ground distribution, starting and charging systems
- Anti-lock brakes, cruise control, shift interlock and supplemental restraint systems
- Manual HVAC, blower, A/C clutch, temperature-control and cooling-fan circuitry where provided
- Exterior lighting, headlights, interior lighting, horn and wiper/washer systems
- Anti-theft, door locks, mirrors, windows and power-seat circuits
- Instrument cluster, radio, navigation/telematics and warning-system wiring
- Cutaway and stripped-chassis distinctions shown where the original diagrams provide them
Table of Content
Engine Performance & Powertrain
- 2015: 5.4L CNG Engine Performance with TorqShift (5-part), 5.4L Flex Fuel with TorqShift (5-part), 5.4L LPG with TorqShift (5-part), 6.8L Engine Performance (5-part), 6.8L CNG (5-part), 6.8L LPG (5-part)
- 2016: 5.4L CNG Engine Performance (5-part), 5.4L Flex Fuel (5-part), 5.4L LPG (5-part), 6.8L Engine Performance (5-part), 6.8L CNG (5-part), 6.8L LPG (5-part)
- 2018: 6.2L Flex Fuel Engine Performance (5-part), 6.8L Engine Performance (5-part), 6.8L CNG (5-part), 6.8L LPG (5-part)
- 2019: 6.2L Flex Fuel Engine Performance (5-part), 6.8L Engine Performance (5-part), 6.8L CNG (5-part), 6.8L LPG (5-part)
- 2022: 7.3L Engine Performance Circuit (10-part)
Transmission & Shift Interlock
- 2015: 5.4L CNG, Flex Fuel and LPG TorqShift transmission circuits (2-part each); 6.8L, 6.8L CNG and 6.8L LPG transmission circuits (2-part each)
- 2016: 5.4L CNG, Flex Fuel and LPG transmission circuits (2-part each); 6.8L, 6.8L CNG and 6.8L LPG transmission circuits
- 2018: Transmission circuit
- 2019: Transmission circuit
- 2022: Transmission circuit
- Shift Interlock circuits across all included model years
Air Conditioning & Climate Control
- 2015 Manual A/C Circuit – 2-part
- 2016 Manual A/C Circuit – 2-part
- 2018 Manual A/C Circuit – 2-part
- 2019 Manual A/C Circuit – 3-part
- 2022 Manual A/C Circuit – 2-part
- Cutaway and stripped-chassis HVAC wiring where identified
- Climate-control assembly, blower motor/resistor, A/C clutch, temperature-blend actuator and related control circuits
Braking, Cruise & Driver Controls
- 2015 Anti-lock Brakes with Stability Assist – 2-part
- 2016 Anti-lock Brakes circuit
- 2018 Anti-lock Brakes circuit
- 2019 Anti-lock Brakes circuit
- 2022 Anti-lock Brakes – 2-part
- Cruise Control circuits; 2022 coverage is 2-part
Body Control, Data Networks, Power & Grounds
- Body Control Modules – 3-part on 2015, 2016, 2018 and 2019; 2-part on 2022
- Computer Data Lines – 2-part across the included manuals, including cutaway network layouts on later applications
- Power Distribution – 8-part on 2015, 2016, 2018 and 2019; 6-part on 2022
- Ground Distribution – 4-part on 2015; 3-part on 2016, 2018, 2019 and 2022
- Module power feeds, grounds and CAN/data communication paths
Starting, Charging & Cooling
- Charging circuits across all five model years
- Starting/charging system wiring and battery-distribution connections
- Cooling Fan circuit on 2018, 2019 and 2022 manuals
- Dual-battery wiring where shown by the original schematics
Lighting & Visibility
- Exterior Lights / Backup Lamps circuits
- Headlights circuits; 2022 coverage is 2-part
- Interior / Courtesy Lamps circuits
- Horn circuits, including cutaway-specific layouts where identified
- Wiper/Washer circuits on 2015, 2016, 2018 and 2019 manuals
Security, Access & Body Electrical
- Anti-Theft / Forced Entry circuits
- Power Door Locks circuits
- Power Mirrors / Electrochromic Mirror circuits, including rear-view camera integration on 2016, 2018 and 2019
- Power Seats circuits
- Power Windows circuits
Instrumentation, Radio & Navigation
- Instrument Cluster circuits, including cutaway configurations where provided
- 2015 Base Radio circuit
- 2016, 2018 and 2019 Radio circuits
- 2022 Radio circuit – 2-part
- 2015 Telematics circuit
- 2016, 2018 and 2019 In-Dash Computer circuits
- 2022 Lane Departure Warning circuit
Safety & Warning Systems
- Supplemental Restraints circuits; 2022 coverage is 2-part
- Warning Systems / Chime circuits
File Details
- Files: 5 PDF wiring manuals
- Total pages: 420
- Years included: 2015, 2016, 2018, 2019 and 2022
- Model: Ford E-350 Super Duty Base
- Powertrain coverage: 5.4L, 6.2L, 6.8L and 7.3L sections, including alternative-fuel variants where provided
- Delivery: Digital download links supplied in the included TXT file
- Language: English
