Ford F-250 Super Duty Wiring Diagram Manual 2006 – Electrical Schematics PDF

Vehicle Coverage

• Model: Ford F-250 Super Duty
• Year: 2006
• Engine circuits included: 5.4L, 6.0L Diesel & 6.8L
• Manual: 130-page system wiring-diagram PDF
• File size: approximately 20.38 MB
• Language: English

Circuit selection varies by engine, transmission, cab/body style and installed equipment. Match the relevant diagram to the vehicle configuration.

Technical Highlights

Use these Ford F-250 Super Duty wiring diagrams 2006 to trace electrical circuits and identify connections across the systems included in this manual. The PDF contains system schematics with wiring colours, component labels, connector references and power/ground paths.

• Engine-management and drivetrain electrical circuits.
• Power distribution, ground distribution, starting and charging wiring.
• Lighting, instrumentation, power accessories and warning systems.
• Equipment-specific variants identified in the contents below.

Table of Contents

Original section headings and diagram captions, in PDF order. Page numbers refer to the supplied PDF.

AIR CONDITIONING (p. 1)

• Fig. 1: Automatic A/C Circuit (1 of 2) — p. 2
• Fig. 2: Automatic A/C Circuit (2 of 2) — p. 3
• Fig. 3: Manual A/C Circuit — p. 4

ANTI-LOCK BRAKES (p. 5)

• Fig. 4: Anti-lock Brakes Circuit — p. 6

ANTI-THEFT (p. 7)

• Fig. 5: Forced Entry Circuit — p. 8

COMPUTER DATA LINES (p. 9)

• Fig. 6: Computer Data Lines Circuit — p. 10

COOLING FAN 6.0L DIESEL (p. 11)

• Fig. 7: 6.0L Diesel, Cooling Fan Circuit — p. 12

CRUISE CONTROL 5.4L (p. 13)

• Fig. 8: 5.4L, Cruise Control Circuit — p. 14
• 6.0L DIESEL — p. 15
• Fig. 9: 6.0L Diesel, Cruise Control Circuit — p. 16
• 6.8L — p. 17
• Fig. 10: 6.8L, Cruise Control Circuit — p. 18

DEFOGGERS (p. 19)

• Fig. 11: Heated Mirrors Circuit — p. 20

ENGINE PERFORMANCE 5.4L (p. 21)

• Fig. 12: 5.4L, Engine Performance Circuit (1 of 5) — p. 22
• Fig. 13: 5.4L, Engine Performance Circuit (2 of 5) — p. 23
• Fig. 14: 5.4L, Engine Performance Circuit (3 of 5) — p. 24
• Fig. 15: 5.4L, Engine Performance Circuit (4 of 5) — p. 25
• Fig. 16: 5.4L, Engine Performance Circuit (5 of 5) — p. 26
• 6.0L DIESEL — p. 27
• Fig. 17: 6.0L Diesel, Engine Performance Circuit (1 of 5) — p. 28
• Fig. 18: 6.0L Diesel, Engine Performance Circuit (2 of 5) — p. 29
• Fig. 19: 6.0L Diesel, Engine Performance Circuit (3 of 5) — p. 30
• Fig. 20: 6.0L Diesel, Engine Performance Circuit (4 of 5) — p. 31
• Fig. 21: 6.0L Diesel, Engine Performance Circuit (5 of 5) — p. 32
• 6.8L — p. 33
• Fig. 22: 6.8L, Engine Performance Circuit (1 of 5) — p. 34
• Fig. 23: 6.8L, Engine Performance Circuit (2 of 5) — p. 35
• Fig. 24: 6.8L, Engine Performance Circuit (3 of 5) — p. 36
• Fig. 25: 6.8L, Engine Performance Circuit (4 of 5) — p. 37
• Fig. 26: 6.8L, Engine Performance Circuit (5 of 5) — p. 38

EXTERIOR LIGHTS (p. 39)

• Fig. 27: Exterior Lamps & Trailer Connector Circuit (1 of 3) — p. 40
• Fig. 28: Exterior Lamps & Trailer Connector Circuit (2 of 3) — p. 41
• Fig. 29: Exterior Lamps & Trailer Connector Circuit (3 of 3) — p. 42
• 5.4L — p. 43
• Fig. 30: 5.4L, Back-up Lamps Circuit — p. 44
• 6.0L DIESEL — p. 45
• Fig. 31: 6.0L Diesel, Back-up Lamps Circuit — p. 46
• 6.8L — p. 47
• Fig. 32: 6.8L, Back-up Lamps Circuit — p. 48

GROUND DISTRIBUTION (p. 49)

• Fig. 33: Ground Distribution Circuit (1 of 7) — p. 50
• Fig. 34: Ground Distribution Circuit (2 of 7) — p. 51
• Fig. 35: Ground Distribution Circuit (3 of 7) — p. 52
• Fig. 36: Ground Distribution Circuit (4 of 7) — p. 53
• Fig. 37: Ground Distribution Circuit (5 of 7) — p. 54
• Fig. 38: Ground Distribution Circuit (6 of 7) — p. 55
• Fig. 39: Ground Distribution Circuit (7 of 7) — p. 56

HEADLIGHTS (p. 57)

• Fig. 40: Autolamps Circuit, W/ DRL — p. 58
• Fig. 41: Autolamps Circuit, W/O DRL — p. 59
• Fig. 42: Headlamps Circuit, W/ DRL — p. 60
• Fig. 43: Headlamps Circuit, W/O DRL — p. 61

HORN (p. 62)

• Fig. 44: Horn Circuit — p. 63

INSTRUMENT CLUSTER (p. 64)

• Fig. 45: Instrument Cluster Circuit (1 of 2) — p. 65
• Fig. 46: Instrument Cluster Circuit (2 of 2) — p. 66
• Fig. 47: Overhead Console Circuit — p. 67

INTERIOR LIGHTS (p. 68)

• Fig. 48: Courtesy Lamps Circuit (1 of 3) — p. 69
• Fig. 49: Courtesy Lamps Circuit (2 of 3) — p. 70
• Fig. 50: Courtesy Lamps Circuit (3 of 3) — p. 71
• Fig. 51: Instrument Illumination Circuit (1 of 2) — p. 72
• Fig. 52: Instrument Illumination Circuit (2 of 2) — p. 73

NAVIGATION (p. 74)

• Fig. 53: Parking Assistant Circuit — p. 75

POWER DISTRIBUTION (p. 76)

• Fig. 54: Power Distribution Circuit (1 of 5) — p. 77
• Fig. 55: Power Distribution Circuit (2 of 5) — p. 78
• Fig. 56: Power Distribution Circuit (3 of 5) — p. 79
• Fig. 57: Power Distribution Circuit (4 of 5) — p. 80
• Fig. 58: Power Distribution Circuit (5 of 5) — p. 81

POWER DOOR LOCKS (p. 82)

• Fig. 59: Power Door Locks Circuit, W/O Keyless Entry — p. 83

POWER MIRRORS (p. 84)

• Fig. 60: Electronic Day/Night Mirror Circuit — p. 85
• Fig. 61: Power Mirrors Circuit — p. 86

POWER SEATS (p. 87)

• Fig. 62: Adjustable Pedal Circuit — p. 88
• Fig. 63: Climate Control Seats Circuit — p. 89
• Fig. 64: Driver Power Seat Circuit — p. 90
• Fig. 65: Passenger Power Seat Circuit — p. 91

POWER TOP/SUNROOF (p. 92)

• Fig. 66: Power Top/Sunroof Circuit — p. 93

POWER WINDOWS (p. 94)

• Fig. 67: Power Windows Circuit, Crew Cab (1 of 2) — p. 95
• Fig. 68: Power Windows Circuit, Crew Cab (2 of 2) — p. 96
• Fig. 69: Power Windows Circuit, Except Crew Cab — p. 97

RADIO (p. 98)

• Fig. 70: Radio Circuit — p. 99

SHIFT INTERLOCK (p. 100)

• Fig. 71: Shift Interlock Circuit — p. 101

STARTING/CHARGING 5.4L (p. 102)

• Fig. 72: 5.4L, Charging Circuit — p. 103
• Fig. 73: 5.4L, Starting Circuit — p. 104
• 6.0L DIESEL — p. 105
• Fig. 74: 6.0L Diesel, Charging Circuit, W/ Dual Generators — p. 106
• Fig. 75: 6.0L Diesel, Charging Circuit, W/O Dual Generators — p. 107
• Fig. 76: 6.0L Diesel, Starting Circuit, A/T — p. 108
• Fig. 77: 6.0L Diesel, Starting Circuit, M/T — p. 109
• 6.8L — p. 110
• Fig. 78: 6.8L, Charging Circuit — p. 111
• Fig. 79: 6.8L, Starting Circuit — p. 112

SUPPLEMENTAL RESTRAINTS (p. 113)

• Fig. 80: Supplemental Restraints Circuit — p. 114

TRANSMISSION (p. 115)

• Fig. 81: 4WD Circuit — p. 116
• 5.4L — p. 117
• Fig. 82: 5.4L, A/T Circuit (1 of 2) — p. 118
• Fig. 83: 5.4L, A/T Circuit (2 of 2) — p. 119
• 6.0L DIESEL — p. 120
• Fig. 84: 6.0L Diesel, A/T Circuit (1 of 2) — p. 121
• Fig. 85: 6.0L Diesel, A/T Circuit (2 of 2) — p. 122
• 6.8L — p. 123
• Fig. 86: 6.8L, A/T Circuit (1 of 2) — p. 124
• Fig. 87: 6.8L, A/T Circuit (2 of 2) — p. 125

WARNING SYSTEMS (p. 126)

• Fig. 88: Warning Systems Circuit, W/ Remote/Keyless Entry — p. 127
• Fig. 89: Warning Systems Circuit, W/O Remote/Keyless Entry — p. 128

WIPER/WASHER (p. 129)

• Fig. 90: Wiper/Washer Circuit — p. 130
