Ford Fiesta Wiring Diagram Manual 2015–2019 – 1.0L Turbo, 1.6L & 1.6L Turbo Electrical Schematics PDF

Vehicle Coverage

• 2015 Ford Fiesta ST – 1.6L source vehicle; manual also contains 1.0L Turbo and 1.6L Turbo system sections
• 2016 Ford Fiesta ST – 1.6L source vehicle; manual also contains 1.0L Turbo and 1.6L Turbo system sections
• 2018 Ford Fiesta Titanium – 1.6L source vehicle; manual also contains 1.6L Turbo system sections
• 2019 Ford Fiesta S – 1.6L source vehicle; manual also contains 1.6L Turbo system sections
• Package: 4 PDF wiring manuals / 401 pages
• Language: English

Technical Highlights

• Factory-style electrical schematics for selected Ford Fiesta applications
• Engine-performance wiring for 1.0L Turbo, 1.6L and 1.6L Turbo powertrains where included
• Transmission, shift-interlock, starting and charging circuits
• Body Control Modules, computer data lines and module communications
• Power distribution and ground distribution diagrams
• Automatic and manual A/C, cooling fan, defogger and electronic power steering circuits
• ABS with and without Electronic Stability Program
• Exterior lamps, headlights, courtesy lamps, horn and wiper/washer circuits
• Keyless-entry, anti-theft, locks, mirrors, windows, seats, sunroof and trunk-release wiring
• Instrument cluster, navigation, SYNC, radio, rear camera, parking-assist and restraint-system diagrams

Table of Content

Air Conditioning, Cooling & Defogging

• Automatic A/C Circuit – 4-part across all included years
• Manual A/C Circuit – 4-part across all included years
• 2015 & 2016: 1.0L Turbo, 1.6L and 1.6L Turbo Cooling Fan circuits
• 2018 & 2019: 1.6L and 1.6L Turbo Cooling Fan circuits
• Defoggers Circuit on 2015, 2016 and 2018 manuals

Brakes, Steering & Cruise Control

• Anti-lock Brakes Circuit with Electronic Stability Program
• Anti-lock Brakes Circuit without Electronic Stability Program
• Cruise Control Circuit – 2-part across all included years
• Electronic Power Steering Circuit across all included years

Security, BCM & Data Networks

• Forced Entry Circuit with Keyless Entry – 4-part
• Forced Entry Circuit without Keyless Entry – 2-part
• Passive Anti-theft Circuit with Keyless Entry
• Passive Anti-theft Circuit without Keyless Entry
• Body Control Modules Circuit
• Computer Data Lines Circuit – 2-part

Engine Performance

• 2015 & 2016: 1.0L Turbo Engine Performance (6-part), 1.6L Engine Performance (4-part), 1.6L Turbo Engine Performance (6-part)
• 2018 & 2019: 1.6L Engine Performance (4-part) and 1.6L Turbo Engine Performance (6-part)

Transmission, Starting & Charging

• Transmission Circuit – 2-part across all included years
• Shift Interlock Circuit
• Charging Circuit
• Starting Circuit with Push Button Start
• Starting Circuit without Push Button Start

Power Distribution & Grounds

• Power Distribution Circuit – 6-part across all included years
• Ground Distribution Circuit – 4-part across all included years

Lighting & Visibility

• Backup Lamps Circuit
• Exterior Lamps Circuit – 3-part
• Headlights Circuit – 2-part
• Courtesy Lamps Circuit – 2-part
• Instrument Illumination Circuit
• Horn Circuit
• Wiper/Washer Circuit

Doors, Mirrors, Windows & Body Electrical

• Power Door Locks with Keyless Entry – 4-part
• Power Door Locks without Keyless Entry – 2-part
• Electrochromic Mirror Circuit with Rain Sensor
• Electrochromic Mirror Circuit without Rain Sensor
• Power Mirrors Circuit
• Power Windows with Intelligent Windows – 2-part
• Power Windows without Intelligent Windows
• Power Seats Circuit
• Power Top/Sunroof Circuit
• Trunk Release Circuit

Instrumentation, Navigation & Audio

• Instrument Cluster Circuit – 2-part
• Navigation Circuit with SYNC GEN 1 – 2-part
• Navigation Circuit with SYNC GEN 2 – 2-part
• Parking Assistant Circuit
• Rear Camera Circuit
• Base Radio Circuit
• Premium Radio with SYNC GEN 1 – 2-part
• Premium Radio with SYNC GEN 2 – 2-part

Safety & Warning Systems

• Supplemental Restraints Circuit – 3-part
• Warning Systems Circuit

File Details

• Files: 4 PDF wiring manuals
• Total pages: 401
• Total size: approximately 21.40 MB
• Years included: 2015, 2016, 2018 and 2019
• Model: Ford Fiesta
• Powertrain coverage: 1.0L Turbo, 1.6L and 1.6L Turbo sections where provided
• Delivery: Digital download links supplied in the included TXT file
• Language: English
