Ford Focus Wiring Diagram Manual 2015–2018 – Electric, 1.0L Turbo, 2.0L, 2.3L RS Electrical Schematics PDF

Vehicle Coverage

• 2015 Ford Focus Electric – source manual with Electric and conventional Focus circuit coverage
• 2016 Ford Focus RS – 2.3L source manual with Electric, RS and conventional Focus circuit coverage
• 2018 Ford Focus SE – 1.0L source manual with Electric, RS and conventional Focus circuit coverage
• Powertrain coverage: Electric, 1.0L Turbo, 2.0L, 2.0L Turbo, 2.0L Flex Fuel and 2.3L Turbo sections where provided
• Package: 3 PDF wiring manuals / 730 pages
• Language: English

Technical Highlights

• Factory-style electrical schematics for selected Ford Focus model years
• Electric-vehicle high-voltage battery, DC/DC converter and electric powertrain wiring
• Gasoline engine-performance wiring for 1.0L Turbo, 2.0L, 2.0L Turbo, 2.0L Flex Fuel and 2.3L Turbo applications where included
• Automatic transmission, AWD / RS and electric driveline circuits where provided
• Body Control Module, Generic Electronic Module and computer data line / CAN networks
• Power distribution, ground distribution, starting and charging circuits
• ABS, cruise control, electronic power steering and shift-interlock wiring
• Automatic/manual A/C, cooling fan and defogger circuits
• Exterior lighting, headlamps, horn, wiper/washer and rear-camera systems
• Power door locks, mirrors, windows, seats, sunroof and trunk-release wiring
• Instrument cluster, radio/SYNC/Sony, navigation, parking-assist and restraint-system diagrams

Table of Content

Air Conditioning & Thermal Management

• Automatic A/C Circuit – Electric
• Automatic A/C Circuit – Except Electric / RS variants
• Manual A/C Circuit
• Cooling Fan Circuit – Electric and conventional applications
• Defoggers Circuit – Electric and conventional applications

Brakes, Steering & Cruise Control

• Anti-lock Brakes Circuit – Electric and Except Electric variants
• Cruise Control Circuit – Electric and conventional applications
• Electronic Power Steering Circuit
• Shift Interlock Circuit – Electric and Except Electric variants

Security, BCM & Data Networks

• Forced Entry / Anti-Theft Circuits – Electric, Intelligent Access and non-Intelligent Access configurations
• Passive Anti-Theft Circuits
• Body Control Module Circuits – Electric and conventional applications
• Generic Electronic Module circuits where provided
• Computer Data Lines / CAN Network Circuits – Electric, RS and conventional variants

Engine Performance & Electric Powertrain

• Electric: Electric Engine Performance circuits including high-voltage battery, DC/DC converter and EV control networks
• 1.0L Turbo: Engine Performance circuits
• 2.0L: Engine Performance circuits
• 2.0L Turbo: Engine Performance circuits
• 2.0L Flex Fuel: Engine Performance circuits where provided
• 2.3L Turbo / RS: Engine Performance circuits where provided

Transmission & Drivetrain

• 1.0L Turbo A/T Circuit
• 2.0L / 2.0L Flex Fuel A/T Circuit
• 2.0L Turbo A/T Circuit
• 2.3L Turbo AWD / RS Circuit
• Electric A/T / driveline circuits

Starting, Charging, Power & Grounds

• 1.0L Turbo Charging and Starting Circuits
• 2.0L / 2.0L Flex Fuel Charging and Starting Circuits
• 2.0L Turbo Charging and Starting Circuits
• 2.3L Turbo Charging and Starting Circuits where provided
• Electric low-voltage / DC-DC power circuitry
• Power Distribution circuits for Electric, RS and conventional applications
• Ground Distribution circuits for Electric and conventional applications

Lighting & Visibility

• Backup Lamps circuits
• Exterior Lamps circuits
• Headlight circuits including HID and non-HID configurations where provided
• Horn Circuit
• Wiper / Washer circuits – Electric, RS and conventional variants

Body, Doors, Mirrors, Seats & Windows

• Power Door Locks circuits with Intelligent Access and conventional configurations
• Power Mirrors circuits with and without door modules, including RS variants
• Power Windows circuits with multiple door-module / rear-window configurations
• Heated Seats, Heated Steering Wheel and Power Seats circuits
• Power Top / Sunroof Circuit
• Trunk Release Circuit – Electric and conventional applications

Instrumentation, Camera, Audio & Driver Assistance

• Instrument Cluster circuits – Electric and conventional applications
• Parking Assistant Circuit – Electric and conventional applications
• Rear Camera circuits – Electric, RS and Except Electric / RS variants
• Base Radio circuits
• Premium Radio circuits
• Sony Radio circuits – RS and non-RS variants
• SYNC Radio circuits including GEN 1 / GEN 3 configurations where provided

Safety & Restraints

• Supplemental Restraints circuits – RS and Except RS variants
• Warning System circuits
• Seat-belt / restraint control wiring and related module connections

File Details

• Files: 3 PDF wiring manuals
• Total pages: 730
• Total size: approximately 42.13 MB
• Years included: 2015, 2016 and 2018
• Model: Ford Focus
• Delivery: Digital download links supplied in the included TXT file
• Language: English
