Vehicle Coverage
- 2015 Ford Mustang – 2.3L Turbo, 3.7L and 5.0L engine-performance wiring sections
- 2016 Ford Mustang – 2.3L Turbo, 3.7L, 5.0L and 5.2L wiring sections
- 2019 Ford Mustang – 2.3L Turbo, 5.0L and 5.2L wiring sections
- 2020 Ford Mustang – 2.3L Turbo, 5.0L, 5.2L and 5.2L supercharged wiring sections
- 2022 Ford Mustang Mach-E – electric powertrain and high-voltage electrical systems
- Package: 5 PDF wiring manuals / 729 pages
- Language: English
Technical Highlights
- Engine performance and powertrain circuits
- Automatic transmission and shift-interlock wiring
- Anti-lock brake system (ABS) circuits
- Body Control Module (BCM) wiring
- Computer data lines and vehicle network communication
- Power distribution and ground distribution
- Starting and charging systems for ICE models
- Electronic power steering and electronic suspension
- Automatic air conditioning and thermal-management circuits
- Exterior lighting, headlights and interior lighting
- Anti-theft, power locks, mirrors, windows and access systems
- Power seats, memory systems and convertible top / sunroof circuits
- Instrument cluster, warning systems and horn circuits
- Radio, navigation, cameras and blind-spot related circuits
- Supplemental restraints / airbag wiring
- Trunk, tailgate, fuel-door and wiper / washer systems
- Mustang Mach-E high-voltage battery, cooling and electric-drive circuits
- Mustang Mach-E active grille shutter and pedestrian-alert circuits
Table of Content
Powertrain & Engine Management
- 2015: 2.3L Turbo Engine Performance (6-part), 3.7L Engine Performance (6-part), 5.0L Engine Performance (6-part)
- 2016: 2.3L Turbo Engine Performance (6-part), 3.7L Engine Performance (6-part), 5.0L Engine Performance (6-part), 5.2L Engine Performance (7-part)
- 2019: 2.3L Turbo Engine Performance (8-part), 5.0L Engine Performance (11-part), 5.2L Engine Performance (7-part)
- 2020: 2.3L Turbo Engine Performance (8-part), 5.0L Engine Performance (11-part), 5.2L Engine Performance (7-part), 5.2L Supercharged Engine Performance (7-part)
- 2022 Mach-E: Electric Engine Performance (20-part)
- Cooling Fan circuits
Transmission & Shift Interlock
- 2015 Transmission Circuit (2-part)
- 2016 Transmission Circuit (2-part)
- 2019 Transmission Circuit (3-part)
- 2020 2.3L Turbo Transmission Circuit (3-part)
- 2020 5.0L Transmission Circuit (3-part)
- 2020 5.2L Transmission Circuit (3-part)
- 2020 5.2L Supercharged Transmission Circuit (4-part)
- 2022 Mach-E A/T Circuit (3-part)
- Shift Interlock circuits
- 2022 Electric Parking Brake circuit
Electrical Power, Distribution & Grounds
- Power Distribution circuits
- Ground Distribution circuits
- Starting / Charging circuits for 2015–2020 applications
- Battery, fuse and relay distribution paths
- Power and ground feeds to body, chassis and powertrain modules
CAN, Computer Data & Control Modules
- Body Control Modules
- Computer Data Lines
- CAN / module communication networks
- Instrument Cluster communication
- Module power, network and diagnostic connections
Braking, Steering & Chassis
- Anti-lock Brakes (ABS)
- Electronic Power Steering
- Electronic Suspension where equipped
- Cruise Control circuits
HVAC & Thermal Management
- Automatic A/C circuits – 3-part ICE applications
- Automatic A/C circuits – 4-part Mustang Mach-E application
- Cooling Fan circuits
- Defogger circuits where equipped
- Evaporator and cabin temperature sensing
- Blower motor and blower control circuits
- Mustang Mach-E high-voltage battery chiller
- Cabin coolant heater and coolant-pump circuits
- High-voltage battery coolant diverter valve
- Transmission-fluid pump and thermal-management circuits
- Ambient-air and coolant temperature sensing
Lighting & Visibility
- Exterior Lights / Backup Lamps
- Headlights
- Interior Lights / Courtesy Lamps
- Horn
- Wiper / Washer
- Defoggers
Anti-Theft, Body, Doors & Access
- Anti-Theft circuits
- Body Control Modules
- Power Door Locks
- Power Mirrors / Electrochromic Mirror circuits
- Power Windows
- Trunk, Tailgate and Fuel Door circuits
- 2022 Mach-E Front Trunk Release
- 2022 Mach-E Active Grille Shutter
Seats, Memory & Comfort Systems
- Power Seats
- Climate-Control Seats where equipped
- Driver Memory Seat circuits
- Memory Systems
- Power Top / Sunroof circuits for applicable Mustang models
Safety & Restraints
- Supplemental Restraints / Airbag circuits
- Warning Systems
- Chime circuits
- 2022 Mach-E Pedestrian Alert circuit
Infotainment, Navigation & Driver Assistance
- Radio / audio system circuits
- Navigation circuits
- Blind Spot Information System circuits on applicable ICE models
- 2022 Mach-E All Around Vision Camera circuit
- Cruise Control circuits
Instrumentation & Driver Information
- Instrument Cluster circuits
- Warning Systems
- Chime circuits
- Vehicle data and module communication paths
2022 Mustang Mach-E Electric Systems
- Electric Engine Performance – 20-part circuit set
- High-voltage battery and battery junction-box circuits
- Battery Energy Control Module related wiring
- High-voltage battery coolant and chiller circuits
- Cabin coolant heater and cabin-heater coolant pump
- Direct-current / direct-current (DC/DC) converter control
- Off-board charge controller related circuits
- Primary drive unit and transmission-fluid pump circuits
- Electric powertrain control and diagnostic communication
- Active Grille Shutter and Pedestrian Alert circuits
File Details
- Files: 5 PDF manuals
- Total pages: 729
- Years included: 2015, 2016, 2019, 2020 and 2022
- 2022 coverage: Ford Mustang Mach-E electric
- Delivery: Digital download links supplied in the included TXT file
- Language: English
