Ford Transit-350 & Transit-350 HD Wiring Diagrams 2015, 2016, 2018, 2019, 2020 & 2022 – Complete Electrical Workshop Manual PDF

Vehicle Coverage

• 2015 Ford Transit-350 XL – 3.2L Turbo Diesel, 3.5L Turbo and 3.7L electrical systems
• 2016 Ford Transit-350 HD Base – 3.2L Turbo Diesel, 3.5L Turbo, 3.7L, 3.7L CNG and 3.7L LPG coverage
• 2018 Ford Transit-350 XL – 3.2L Turbo Diesel, 3.5L Turbo, 3.7L, CNG, Flex Fuel and LPG variants
• 2019 Ford Transit-350 HD XLT – diesel, turbo, 3.7L, CNG, Flex Fuel and LPG electrical coverage where provided
• 2019 Ford Transit-350 PTV – diesel, turbo, 3.7L, CNG, Flex Fuel and LPG electrical coverage where provided
• 2020 Ford Transit-350 HD PTV – 2.0L Turbo Diesel, 3.5L and 3.5L Turbo electrical systems
• 2022 Ford Transit-350 HD Base – 3.5L Flex and 3.5L Turbo electrical systems
• Package: 7 PDF wiring manuals / 1,115 pages
• Language: English

Technical Highlights

• Factory-style electrical schematics across Transit-350 and Transit-350 HD applications
• Engine performance wiring for 2.0L Turbo Diesel, 3.2L Turbo Diesel, 3.5L, 3.5L Turbo, 3.7L, CNG, LPG and Flex Fuel variants where included
• Automatic transmission, shift-interlock and 2022 electric parking-brake circuitry
• Body Control Module (BCM), computer data lines and module communication networks
• Power distribution, ground distribution, charging and starting systems
• ABS, cruise control and electronic power steering on later applications
• Manual/automatic HVAC, cooling-fan and defogger circuits
• Exterior lighting, headlights, interior lighting, horn and wiper/washer systems
• Anti-theft, door locks, mirrors, windows, power seats and body-access functions
• Radio/SYNC, navigation, Crew Chief and Blind Spot Information System circuits where equipped
• Supplemental restraints, warning systems and 2022 active-bodywork / pedestrian-alert circuits

Table of Content

Engine Performance & Cooling

• 2015 Transit-350 XL: 3.2L Turbo Diesel Engine Performance (9-part), 3.5L Turbo (6-part), 3.7L (6-part); dedicated cooling-fan circuits
• 2016 Transit-350 HD Base: 3.2L Turbo Diesel (9-part), 3.5L Turbo (6-part), 3.7L (6-part), 3.7L CNG (6-part), 3.7L LPG (6-part); matching cooling-fan circuits
• 2018 Transit-350 XL: 3.2L Turbo Diesel (9-part), 3.5L Turbo (6-part), 3.7L (6-part), 3.7L CNG (6-part), 3.7L Flex Fuel (6-part), 3.7L LPG (6-part); matching cooling-fan circuits
• 2019 Transit-350 HD XLT / Transit-350 PTV: 3.2L Turbo Diesel (9-part), 3.5L Turbo (6-part), 3.7L (6-part), CNG, Flex Fuel and LPG engine-performance sections; dedicated cooling-fan circuits
• 2020 Transit-350 HD PTV: 2.0L Turbo Diesel Engine Performance (11-part), 3.5L (10-part), 3.5L Turbo (12-part); dedicated cooling-fan circuits
• 2022 Transit-350 HD Base: 3.5L Flex Engine Performance (10-part), 3.5L Turbo (12-part); dedicated cooling-fan circuits

Transmission, Shift Interlock & Starting/Charging

• 2015 transmission circuits: 3.2L Turbo Diesel, 3.5L Turbo and 3.7L (2-part each)
• 2016 transmission circuits: 3.2L Turbo Diesel, 3.5L Turbo, 3.7L, 3.7L CNG and 3.7L LPG (2-part each)
• 2018 transmission circuits: 3.2L Turbo Diesel, 3.5L Turbo, 3.7L, 3.7L CNG, 3.7L Flex Fuel and 3.7L LPG (2-part each)
• 2019 transmission circuits across diesel, turbo, 3.7L, CNG and alternative-fuel variants where provided
• 2020 A/T circuits: 2.0L Turbo Diesel, 3.5L and 3.5L Turbo (3-part each)
• 2022 A/T circuit (3-part)
• Shift Interlock circuits; 2022 Electric Parking Brake circuit
• Starting / Charging circuits for applicable engine variants; later manuals include multi-part charging circuits

Power Distribution, Grounds & Data Networks

• Power Distribution – 10-part circuits on 2015–2019 manuals; 8-part circuits on 2020 and 2022
• Ground Distribution – 7-part circuits on 2015–2019; 10-part circuits on 2020 and 2022
• Body Control Module circuits (2-part)
• Computer Data Lines – 3-part on 2015–2019; 4-part on 2020 and 2022
• CAN/data-network, module communication, power and ground feeds

HVAC & Climate Systems

• Manual A/C – 4-part circuits on 2015, 2016, 2018 and 2019
• Manual A/C – 5-part circuit on 2020
• Automatic A/C – 5-part circuit on 2022
• Defoggers, blower-motor, HVAC control/module and temperature-control wiring

Braking, Steering & Driver Controls

• Anti-lock Brakes (ABS)
• Cruise Control circuits (2-part)
• Electronic Power Steering – 2020 and 2022

Lighting & Visibility

• Exterior Lights / Backup Lamps
• Headlights – single circuit on earlier applications; 2-part on 2020 and 2022
• Interior / Courtesy lighting circuits
• Horn and Wiper/Washer circuits

Security, Access & Body Electrical

• Anti-Theft / Forced Entry circuits
• Power Door Locks
• Power Mirrors / Electrochromic Mirror circuits
• Power Windows and Power Seats
• Retractable Running Boards on applicable 2018/2019 applications
• Power Sliding Door circuits on 2020 and 2022
• 2022 Active Grille Shutter and related active-bodywork circuitry

Instrumentation, Navigation & Infotainment

• Instrument Cluster circuits
• Radio circuits; later manuals include SYNC coverage
• Crew Chief circuits on earlier Transit applications
• Blind Spot Information System circuits on 2020 and 2022
• Computer-data links to infotainment and driver-information modules

Safety & Warning Systems

• Supplemental Restraints / Airbag circuits (3-part)
• Warning Systems / Chime circuits
• 2022 Pedestrian Alert circuit

File Details

• Files: 7 PDF wiring manuals
• Total pages: 1,115
• Years included: 2015, 2016, 2018, 2019, 2020 and 2022
• Variants represented: Transit-350 XL / PTV and Transit-350 HD Base / XLT / PTV
• Delivery: Digital download links supplied in the included TXT file
• Language: English
