Vehicle Coverage
- Lamborghini Gallardo MY2004
- Early Gallardo technical documentation
- Manual gearbox coverage
- E-Gear coverage
- 10-cylinder engine component coverage
- AWD drivetrain and front/rear differential systems
- MY2004 USA electrical wiring diagrams
- Publication references inside manual: 12/2003 and 12/2004
- Total PDF: 1,397 pages
- Core Gallardo technical content: approximately 1,376 pages
- Approx. file size: 53.9 MB
- Format: PDF
- Language: English
Technical Highlights
- 10-cylinder engine component breakdowns
- Engine maintenance and servicing
- Engine removal and installation
- Camshaft / timing system
- Crankshaft and connecting rods
- Pistons and cylinder heads
- Engine oil and lubrication
- Cooling system
- Intake and fuel systems
- Emission control
- Exhaust system
- Manual transmission
- Clutch servicing and bleeding
- E-Gear hydraulic actuator system
- E-Gear valve group
- Gearbox removal and installation
- Front differential
- Rear differential
- Propeller shaft and AWD drivetrain
- Front and rear driveshafts
- ABS / ESP braking system
- Front and rear brake servicing
- Suspension
- Steering and power steering
- Wheels and tyres
- Air conditioning
- Airbag / restraint system
- Body and frame
- Dashboard and interior equipment
- Diagnostic systems
- OBD II diagnostic connection
- Power supply and control-unit diagrams
- Lighting circuits
- ZKE system
- K-line diagnostic communication
- Radio / audio wiring
- E-Gear electrical schematics
- Body electrical circuits
Table of Content
- Illustrated Engine & Parts Reference
- Crankcase
- Lower crankcase
- Oil sump
- Distribution / timing cover
- Left cylinder-head covers
- Left cylinder head
- Right cylinder-head covers
- Right cylinder head
- Crankshaft and connecting rods
- Pistons
- Right-head timing system
- Left-head timing system
- Main timing system
- Lubrication System
- Oil filter
- Oil pump
- Oil-system radiator
- Oil lines and temperature sensing
- Cooling System
- Water pump
- Cooling-system piping
- Expansion tank
- Water temperature sensors
- Radiators
- Electric fans
- Air conveyors
- Intake & Engine Air
- Intake manifold
- Motor-driven throttle bodies
- TMAP sensor
- Fuel injectors
- Intake actuators
- Air-filter box
- Fuel & Emissions
- Right fuel tank
- Left fuel tank
- Fuel-tank installation
- Fuel system
- Fuel filters
- Solenoid valves
- Emission-control system
- Oxygen sensors
- Exhaust System
- Exhaust manifolds
- Catalytic converter assemblies
- Oxygen sensors
- Thermocouples
- Silencer assemblies
- Exhaust terminals
- Vacuum-controlled exhaust components
- Air Conditioning
- A/C compressor
- Condenser
- Receiver / dehydrator
- Refrigerant pipes
- HVAC unit
- Climate distribution box
- Clutch
- Clutch and flywheel
- Thrust bearing
- Clutch hydraulic service
- Gearbox & Transmission
- Gearbox assembly
- Gearbox / rear differential case
- Gearbox oil pump
- Mechanical actuator
- Gearbox shifting rods and forks
- Main shaft
- Driven shaft
- Output / dismissal shaft
- Rear differential
- Gear selector controls
- Manual transmission controls
- E-Gear System
- E-Gear actuator assembly
- E-Gear actuator subassemblies
- Actuator group
- Position sensors
- Hydraulic valve group
- Pressure sensor
- Storage accumulator
- High-pressure lines
- Hydraulic connections
- E-Gear removal and installation
- AWD & Differentials
- Propeller shaft
- Front driveshafts
- Rear driveshafts
- Front differential assembly
- Front differential case
- Front differential internals
- Viscous coupling
- Rear differential
- Differential bearings and gears
- Front Suspension
- Front arms
- Upper and lower control arms
- Stabilizer bar
- Wheel carriers
- Shock absorbers
- Springs
- Rear Suspension
- Rear arms
- Stabilizer bar
- Wheel carriers
- Shock absorbers
- Springs
- Steering
- Steering column
- Steering wheel
- Steering switches
- Power steering
- Steering rack
- Hydraulic pump
- Reservoir and lines
- Brake System
- Hydraulic brake system
- ABS / ESP control unit
- Brake lines
- Front brake discs
- Front brake calipers
- Front pads
- Rear brake discs
- Rear brake calipers
- Rear pads
- Hand-brake system
- Brake and clutch pedals
- Power-brake system
- Wheels & Tyres
- Front wheels and tyres
- Rear wheels and tyres
- Rims
- Valves and hub components
- Body & Exterior
- Front bumper
- Rear bumper
- Roof panel
- Front hood
- Heat shields
- Exterior rear-view mirrors
- Windows
- Interior Equipment
- Dashboard assembly
- Dashboard
- Driver-side storage
- Passenger-side storage
- Chassis-related interior components
- Dashboard instruments
- Hi-Fi system
- Dashboard ventilation ducts
- Starting & Ignition
- Alternator and drive belts
- Ignition system
- Starter
- Electrical components
Maintenance & Workshop Procedures
- General Information
- Manual introduction
- General safety rules
- Workshop precautions
- Service personnel information
- Pre-delivery checks
- Scheduled Maintenance
- Scheduled service plan
- Engine checks
- Fluid inspections
- Chassis inspections
- Periodic service operations
- Special Tools
- Engine special tools
- Timing tools
- Workshop service tools
- Engine Maintenance
- Engine-oil level checking
- Engine-oil topping up
- Coolant-level inspection
- Spark-plug checking and replacement
- Belt tension checking and adjustment
- Mechanical engine timing
- Fuel-filter replacement
- Activated-carbon filter replacement
- Coolant replacement
- Engine oil and filter replacement
- Air-filter replacement
- Muffler replacement
- Oxygen-sensor replacement
- Engine / powertrain removal and installation
- Diagnostic Systems
- LARA-AS diagnostic system
- LDAS32 diagnostic system
- Fault-code reading
- Vehicle identification
- Parameter monitoring
- Diagnostic software functions
- Clutch
- Manual gearbox clutch bleeding
- Manual Gearbox
- Shift-control adjustment
- Gearbox and rear-differential oil inspection
- Removal and installation
- E-Gear
- E-Gear removal
- E-Gear installation
- Hydraulic actuator system
- Front Differential
- Differential-oil level inspection
- Brakes & ABS
- Brake-fluid level
- Hand-brake adjustment
- Brake-system bleeding
- Front brake-pad replacement
- Rear brake-pad replacement
- Hand-brake pad replacement
- Suspension & Steering
- Hydraulic-fluid inspection
- Steering and suspension service
- Wheels & Tyres
- Wheel removal and installation
- Tyre-related servicing
- A/C System
- Cabin / pollen-filter replacement
- Airbag
- Passenger airbag replacement
- Restraint-system servicing
- Body & Frame
- Body-component disassembly
- Body-component installation
- Engine trim-panel removal and installation
Electrical Wiring Diagrams
- Display Diagrams
- Electrical diagram identification and layout
- Power Supply
- Main power feeds
- Distribution circuits
- Control Units
- Electronic control modules
- Module power and communication
- LIE System
- EL0401–EL0412 circuit groups
- GFA System
- GFA electrical circuit
- Air Conditioning Electrical System
- A/C system
- Multi-page HVAC wiring
- Sensors and control circuits
- Lighting System
- Number-plate lighting
- Indicators
- Front side markers
- Running lights
- Rear side markers
- Rear fog lamps
- Reverse lamps
- Brake lamps
- High-mounted brake lamp
- High / low beams
- Emergency indicators
- Clearance and threshold lights
- Interior and luggage-compartment lights
- ZKE / Body Access System
- Anti-theft siren
- ZKE antenna
- Volumetric sensor
- Anti-theft exclusion switch
- Left door unlocking and lock circuits
- Right door unlocking and lock circuits
- Anti-theft LEDs
- Engine bonnet microswitch
- Front bonnet microswitch
- Fuel-filler flap motor
- Exterior rear-view mirrors
- Braking Electrical System
- ABS system
- Brake-fluid level sensor
- Brake-pad wear sensor
- Hand-brake microswitch
- Brake-pedal switch
- Airbag System
- Airbag electrical circuits
- Restraint-system control
- E-Gear Electrical System
- E-Gear control circuits
- Actuator system
- Reverse-gear input
- NORM / SPORT / slippery-road selection
- E-Gear control-unit connections
- Radio System
- Radio Symphony II
- Audio-system connections
- Body Electrical
- Windshield washer level
- Windshield wiper motor and pump
- Headlight washer pump
- Warning horns
- Fuel-tank level sensors
- Cooling-fluid temperature sensing
- External temperature sensor
- Alternator warning circuit
- Central instrument panel
- Sun-visor button panel
- Homelink button panel
- Glove-box lighting
- Internal rear-view mirror
- Board computer
- OBD II diagnostic socket
- K-Line System
- Diagnostic communication lines
- Electronic-module diagnostic connections
