Main Coverage
- Transmission description and operation
- Mechatronic valve body and TCM
- Torque converter and lock-up clutch
- Fluid level, drain and refill procedures
- Solenoids, sensors, clutches and planetary gears
- Diagnostics and fault inspection
- Transmission removal and installation
- Torque settings and workshop illustrations
File Details
- Manufacturer: ZF / Land Rover
- Transmission: 8HP70
- Type: 8-speed automatic AWD
- Pages: 182
- Language: English
- Format: PDF
- Delivery: Digital download
Table of Contents
- Maintenance and specifications
- Fluid capacity and specification
- Maintenance intervals
- Lubricants and sealants
- Torque specifications
- Description and operation
- Transmission construction
- Torque converter
- Fluid pump
- Mechatronic valve block
- Solenoids and sensors
- Clutches and brakes
- Planetary gear sets
- Transmission Control Module
- Diagnosis and testing
- Fluid level and condition check
- Visual inspection
- Diagnostic trouble codes
- General procedures
- Fluid level adjustment
- Drain and refill
- Temperature monitoring
- Removal and installation
- Transmission assembly
- Fluid pan and filter
- Valve body and TCM
- Transmission cooler components
- Seals and mounting components
- External controls
- Transmission selector
- Paddle controls
- Emergency park release
