MAN TG3 KNORR Brake System Wiring Diagrams – TGX/TGS Euro 6d (Q4 2020)

This comprehensive 6-part wiring schematic set covers the KNORR Brake System for MAN TG3 TGX and TGS Euro 6d trucks, released Q4 2020 by MAN Truck & Bus SE. These factory-original schematics detail the full electrical architecture of the EBS (Electronic Brake System), auxiliary brake sensors, and trailer brake control modules.

🧩 Coverage includes:

• EBS Steuergerät A756 with ASR, ESP, ABS, EasyStart
• Wheel speed sensors (Drehzahlfühler) and brake lining wear sensors (Bremsbelag) for both front and rear axles
• ESP steering angle sensor, yaw rate sensors, pressure modulator valves
• Off-road brake assist, climbing brake, and anti-jackknife circuit logic
• Trailer ABS control via EBS/TCM module and 7-pin socket
• CAN bus segmentation (C-CAN, I-CAN, CANB Front/Rear)

Each schematic includes factory connector references like X6301, X6302, and signal mappings through YP241, Y280, XP202.

This package is indispensable for:

• Full brake diagnostics and retrofits
• Service operations using MAN MANTIS or diagnostic tools
• Compliance checks and sensor/wire tracing

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
