Porsche Panamera ABS Wiring Diagram Manual (2015–2016)

This official OEM wiring manual provides comprehensive schematics for the Anti-Lock Braking System (ABS) in the Porsche Panamera 2015–2016 models. It is ideal for technicians and enthusiasts working on ABS diagnostics, fault tracing, or ECU connectivity in premium Porsche braking systems.

🚗 Includes detailed diagrams for:

• ABS control unit (including CAN and sensor input/output)

• Wheel speed sensors (all 4 wheels)

• Brake pressure sensor circuit

• Hydraulic unit and electric pump control

• Power supply and ground configuration

• Inter-system connections (with ESC, PSM)

🔍 Compatible with:

• Base, 4, S, 4S, GTS, Turbo, and E-Hybrid Panamera models

• Applicable to both standard and Executive versions

---

Delivery:

The download link will be promptly delivered to your email upon completing the checkout process.
