Volkswagen Caddy 1.6 CR TDI (CAYE) 2011–2015 Wiring Diagram – Instrument Cluster & Sensors

This Volkswagen Caddy 1.6 CR TDI (CAYE) Wiring Diagram provides detailed schematics for the instrument cluster (Kombiinstrument) and related sensors. It is designed for diagnosing, repairing, and maintaining the electrical and electronic systems of the 2011–2015 VW Caddy models.

Systems Covered

• Control Units

  • E18 – Instrument Cluster Control Unit

  • E45 – Electronic Steering Wheel Control Unit

  • E64 – Diagnostic Control Unit

  • E209 – Multimedia Control Unit

  • O2 – CAN System

  • O129 – Immobiliser Coil

• Sensors

  • P1 – Fuel Level Sensor

  • P19 – Washer Fluid Level Sensor

  • S2 – Oil Pressure Switch

  • S7 – Brake Fluid Level Switch

  • S16 – Handbrake Switch

  • T6 – Outside Temperature Sensor

  • Z10 – Oil Level & Temperature Sensor

  • Z12 – Front Left Brake Pad Wear Sensor

  • Z17 – Coolant Level Sensor

• Wiring Information

  • Complete color codes for wiring (BE – Beige, BK – Black, BN – Brown, BU – Blue, DB – Dark Brown, DG – Dark Green, etc.)

  • Transparent documentation of all wiring circuits for the selected configuration (without fog lights, with electro-hydraulic power steering)
