Vehicle Coverage
- 2015 Ford F-350 Super Duty Platinum – 6.2L source vehicle
- 2016 Ford F-350 Super Duty Platinum – 6.7L source vehicle
- 2018 Ford F-350 Super Duty King Ranch – 6.2L source vehicle
- 2019 Ford F-350 Super Duty Lariat – 6.7L source vehicle
- 2020 Ford F-350 Super Duty King Ranch – 7.3L source vehicle
- 2022 Ford F-350 Super Duty XLT – 7.3L source vehicle
- Package: 6 PDF wiring manuals / 921 pages
- Language: English
Technical Highlights
- Factory-style wiring diagrams and circuit identification for selected Ford F-350 Super Duty models
- Engine-performance coverage for 6.2L Flex Fuel, 6.7L Turbo Diesel and 7.3L powertrains where included
- Automatic transmission and 4WD wiring across the supported engines and years
- Body Control Module, Generic Electronic Module and computer data line networks
- Power distribution, ground distribution, charging and starting systems
- HVAC, cooling fan, defogger, ABS, cruise control and steering circuits
- Lighting, horn, wiper/washer, trailer/tow, mirrors, seats, locks, windows and roof systems
- Instrument cluster, navigation, radio, telematics, camera and warning system wiring
- Supplemental restraints, blind spot, lane departure and running-board coverage on later years
Table of Content
Air Conditioning, Cooling & Defogging
- 2015 & 2016: Automatic A/C Circuit and Manual A/C Circuit
- 2018 & 2019: Automatic A/C Circuit plus Manual A/C Circuit with and without Multi-Function Display
- 2020 & 2022: Automatic A/C Circuit and Manual A/C Circuit
- Cooling Fan Circuit and Defoggers Circuit across all included years
Braking, Steering & Cruise Control
- Anti-lock Brakes Circuit across all included years
- 2015–2019: 6.2L Flex Fuel Cruise Control Circuit and 6.7L Turbo Diesel Cruise Control Circuit
- 2020 & 2022: Cruise Control Circuit
- 2018 & 2019: Electronic Power Steering Circuit
- 2020: Adaptive Steering Circuit and Electronic Power Steering Circuit
- 2022: Active Power Steering Circuit and Electronic Power Steering Circuit
- Shift Interlock Circuit across all included years
Security, BCM & Data Networks
- Forced Entry Circuit and Passive Anti-theft Circuit across all included years
- 2015 & 2016: Body Control Modules Circuit
- 2018–2022: Body Control Module Circuit and Generic Electronic Module Circuit
- 2015 & 2016: Computer Data Lines Circuit
- 2018: Computer Data Lines Circuit, Early Production and Late Production
- 2019 & 2020: Computer Data Lines Circuit
- 2022: Computer Data Lines Circuit, Multi-Function Display 4 & 8 Inch and 12 Inch
Engine Performance
- 2015 & 2016: 6.2L Flex Fuel Engine Performance Circuit and 6.7L Turbo Diesel Engine Performance Circuit
- 2018 & 2019: 6.2L Flex Fuel Engine Performance Circuit and 6.7L Turbo Diesel Engine Performance Circuit
- 2020 & 2022: 6.2L Flex Fuel Engine Performance Circuit, 6.7L Turbo Diesel Engine Performance Circuit and 7.3L Engine Performance Circuit
Transmission, 4WD, Starting, Charging & Power
- 2015 & 2016: 6.2L Flex Fuel 4WD Circuit, 6.2L Flex Fuel A/T Circuit, 6.7L Turbo Diesel 4WD Circuit, 6.7L Turbo Diesel A/T Circuit
- 2018 & 2019: 6.2L Flex Fuel 4WD Circuit, 6.2L Flex Fuel A/T Circuit, 6.7L Turbo Diesel 4WD Circuit, 6.7L Turbo Diesel A/T Circuit
- 2020 & 2022: 6.2L Flex Fuel 4WD Circuit, 6.2L Flex Fuel A/T Circuit, 6.7L Turbo Diesel 4WD Circuit, 6.7L Turbo Diesel A/T Circuit, 7.3L 4WD Circuit and 7.3L A/T Circuit
- 2015–2019: 6.2L Flex Fuel Charging Circuit, 6.2L Flex Fuel Starting Circuit, 6.7L Turbo Diesel Charging Circuit with dual/single generator options, and 6.7L Turbo Diesel Starting Circuit
- 2020 & 2022: Charging Circuit with Dual Battery, Charging Circuit with Dual Generators, Charging Circuit with Single Battery, and Starting Circuit
- Power Distribution Circuit and Ground Distribution Circuit across all included years
Lighting, Horn, Visibility & Trailer
- Backup Lamps Circuit, Horn Circuit and Wiper/Washer Circuit across all included years
- 2015 & 2016: Exterior Lamps Circuit, Headlights Circuit and Trailer Tow Circuit
- 2018 & 2019: Exterior Lamps Circuit with and without Halogen Headlamps, Headlights Circuit and Trailer/Camper Adapter Circuit
- 2020 & 2022: Exterior Lamps Circuit with and without LED, Headlights Circuit and Trailer/Camper Adapter Circuit
- Courtesy Lamps Circuit and Instrument Illumination Circuit across all included years
Body, Doors, Mirrors, Seats & Windows
- Power Door Locks Circuit, Power Mirrors Circuit, Electrochromic Mirror Circuit and Power Top/Sunroof Circuit across all included years
- 2015 & 2016: Adjustable Pedal Circuit, Driver’s Memory Seat Circuit, Memory Mirrors Circuit, Climate Control Seats Circuit, Heated Steering Wheel Circuit, multiple Power Seats Circuits, Rear Heated Seats Circuit, Power Windows Circuit (Crew Cab / Except Crew Cab) and Sliding Rear Window Circuit
- 2018 & 2019: Adjustable Pedal Circuit, Driver’s Memory Seat Circuit, Memory Mirrors Circuit, Steering Column Memory Circuit, Climate Control Seats / Front Heated Seats / Multicontour Seats / Heated Steering Wheel circuits, multiple Power Seats Circuits, Rear Heated Seats Circuit, Power Windows Circuit (Crew Cab / Standard Cab / Super Cab), Sliding Rear Window Circuit, Retractable Running Boards Circuit and Tailgate Release Circuit
- 2020 & 2022: Adjustable Pedal Circuit, Driver’s Memory Seat Circuit, Memory Mirrors Circuit, Steering Column Memory Circuit, Front Heated Seats with or without Ventilation, Heated Steering Wheel Circuit, Multicontour Seats Circuit, multiple Power Seats Circuits, Rear Heated Seats Circuit, Power Windows Circuit (Crew Cab / Standard Cab / Super Cab), Sliding Rear Window Circuit, Retractable Running Boards Circuit and Tailgate Release Circuit
Instrumentation, Camera, Audio & Advanced Driver Systems
- Instrument Cluster Circuit across all included years
- 2018–2022: Overhead Console Circuit
- 2015 & 2016: Crew Chief Circuit, Navigation Circuit with or without Sony, Parking Assistant Circuit, Rear Camera Circuit, Base Radio Circuit, Premium Radio Circuit with or without Sony, and SYNC Radio Circuit
- 2018 & 2019: All Around Vision Camera Circuit with or without 360 View, Blind Spot Information System Circuit, Lane Departure Warning Circuit, Navigation Circuit with multiple audio/display variants, Parking Assistant Circuit, Rear Camera Circuit, Base Radio Circuit and Premium Radio Circuit variants
- 2020 & 2022: All Around Vision Camera Circuit with or without 360 View, Blind Spot Information System Circuit, Lane Departure Warning Circuit, Navigation Circuit, Rear Camera Circuit with fixed or loose camera, Telematics Circuit and Radio Circuit
Safety & Monitoring
- Supplemental Restraints Circuit across all included years
- Chime Circuit and Tire Pressure Monitoring Circuit across all included years
File Details
- Files: 6 PDF wiring manuals
- Total pages: 921
- Total size: approximately 50.64 MB
- Years included: 2015, 2016, 2018, 2019, 2020 and 2022
- Model: Ford F-350 Super Duty
- Powertrain coverage: 6.2L Flex Fuel, 6.7L Turbo Diesel and 7.3L sections where provided
- Delivery: Digital download links supplied in the included TXT file
- Language: English
