Vehicle Coverage
- 2020 Ford SSV Plug-in Hybrid Base
- Engine: 2.0L
- Powertrain: Plug-in Hybrid / PHEV
- Manual: 141-page PDF wiring-diagram document
- File size: approximately 8.24 MB
- Language: English
Technical Highlights
- Factory-style wiring schematics for the 2020 Ford SSV Plug-in Hybrid
- 2.0L Plug-in Hybrid engine-performance circuits with 10-part detailed coverage
- High-voltage battery, battery-energy control, DC/DC conversion and service-disconnect wiring
- Hybrid cooling-fan, cabin-heater coolant pump and PHEV thermal-management circuits
- Automatic transmission, transmission control and shift-interlock wiring
- ABS, cruise control, electronic power steering and electronic suspension circuits
- Body Control Modules and computer data-line / CAN network wiring
- Power distribution, ground distribution, charging-related and starting-related circuits
- Exterior lighting, headlights, courtesy lighting, horn and wiper/washer systems
- Power locks, mirrors, windows, seats, memory, sunroof and trunk/fuel-door systems
- Blind-spot, lane-departure, parking-assist, rear-camera and navigation wiring
- Radio, Sony/non-Sony audio, instrument cluster, restraints, TPMS and warning-system circuits
Table of Content
Climate Control & Hybrid Cooling
- Automatic A/C Circuit – 3-part
- Cooling Fan Circuit
- Hybrid Cooling Fan Circuit
- Defoggers Circuit
Brakes, Steering & Chassis
- Anti-lock Brakes Circuit – 2-part
- Cruise Control Circuit – 2-part
- Electronic Power Steering Circuit
- Electronic Suspension Circuit
Security, BCM & Data Networks
- Anti-theft Circuit – 5-part
- Body Control Modules Circuit – 3-part
- Computer Data Lines Circuit – 3-part
2.0L Plug-In Hybrid Engine & High-Voltage Systems
- 2.0L Plug-In Hybrid Engine Performance Circuit – 10-part
- High-voltage battery and battery-energy control wiring
- High-voltage battery service-disconnect circuitry
- DC/DC converter and PHEV electrical-power circuits
- Secondary On-Board Diagnostic Module C / Transmission Control Module wiring
- Cabin coolant-heater and hybrid thermal-management circuits
Transmission & Shift Control
- A/T Circuit – 3-part
- Shift Interlock Circuit
Power Distribution & Grounds
- Power Distribution Circuit – 7-part
- Ground Distribution Circuit – 6-part
Lighting & Visibility
- Backup Lamps Circuit
- Exterior Lamps Circuit with Halogen Headlamps – 5-part
- Exterior Lamps Circuit without Halogen Headlamps – 5-part
- Headlights Circuit – 3-part
- Courtesy Lamps Circuit – 4-part
- Instrument Illumination Circuit – 3-part
- Horn Circuit
- Wiper/Washer Circuit
Mirrors, Seats, Memory & Windows
- Memory Mirrors Circuit – 2-part
- Memory Seat Circuit – 3-part
- Steering Column Memory Circuit
- Electrochromic Mirror Circuit with Lane Keeping Assist System
- Electrochromic Mirror Circuit with Rear View Camera
- Electrochromic Mirror Circuit without Lane Keeping Assist System
- Power Mirrors Circuit – 2-part
- Climate Control Seats Circuit
- Front Heated Seats Circuit
- Heated Steering Wheel Circuit
- Multicontour Seats Circuit
- Power Seats Circuit – 10-Way Driver Seat
- Power Seats Circuit – 10-Way Passenger Seat
- Power Seats Circuit – 4-Way Passenger Seat
- Power Windows Circuit – 2-part
- Power Top / Sunroof Circuit
Driver Assistance, Navigation & Cameras
- Blind Spot Information System Circuit
- Crew Chief Circuit
- Lane Departure Warning Circuit
- Navigation Circuit with Sony – 4-part
- Navigation Circuit without Sony & Touch Screen – 3-part
- Navigation Circuit without Sony with Touch Screen – 4-part
- Parking Assistant Circuit – 2-part
- Rear Camera Circuit – 4.2 Inch Display
- Rear Camera Circuit – Touch Screen Display
- Vehicle Proximity Notification Circuit
Body, Locks, Trunk & Fuel Door
- Power Door Locks Circuit – 5-part
- Fuel Door Release Circuit
- Trunk Release Circuit with Power Decklid
- Trunk Release Circuit without Power Decklid
Instrumentation, Audio & Safety
- Instrument Cluster Circuit – 2-part
- Radio Circuit with Sony – 4-part
- Radio Circuit without Sony & Touch Screen – 3-part
- Radio Circuit without Sony with Touch Screen – 4-part
- Supplemental Restraints Circuit – 3-part
- Chime Circuit – 2-part
- Tire Pressure Monitoring Circuit
File Details
- Files: 1 PDF wiring manual
- Pages: 141
- File size: approximately 8.24 MB
- Year: 2020
- Model: Ford SSV Plug-in Hybrid Base
- Engine: 2.0L
- Delivery: Digital download link supplied in the included TXT file
- Language: English
